    SP-5564
    5x64 HDMI Splitter in Modularized HDMI/Cat.X Out
    • State-of-the-art Silicon Image (founder of HDMI) chipset embedded for utmost compatibility and reliability
    • Support HDMI Deep Color & 3D
    • HDCP compliant
    • PCIe card slot compatible design
    • Each HDMI PCIe card provides HDMI outputs and 1 local input
    • HDMI PCIe card can be built with either HDMI out or Cat.X out
    • Regenerates the HDMI signal
    • HDMI local input for adding another source to the eight outputs
    • Supports default HDMI EDID and has the ability to learn the EDID of displays
    • Extends up to 20m (66ft) of input HDMI cable
    • Extends up to 60m (200ft) of output Cat.X solid UTP cable under HD (720p / 1080i)
    • Extends up to 40m (130ft) of output Cat.X solid UTP cable under Full HD (1080p)
    • Pure unaltered uncompressed 7.1ch digital HDMI over Cat.X cable transmission
    • Allows cascading
    • RS-232 control master and local sources
    • 3RU rack mountable
    Overview

    The SP-5564 5x64 HDMI Splitter in Modularized HDMI/Cat.X Out is the most advanced HDMI splitter with flexible output port expansion capability in the market. The number of HDMI outputs of SP-5564 can be up to 64 in typical HDMI connectors or CAT5 connectors. SP-5564 offers the first HDMI distribution system which can be easily expanded to have more outputs with plug daughter boards to increase the size of high definition HDMI distribution network. Each daughter board offers 8 HDMI signal fan outs with either HDMI or CAT-5 connectors with one extra HDMI connector for another local input. For each CAT5 output port, SP-5564 can transmit Full HD 1080p AV signals up to 40 meters/130 feet distance away through single solid CAT-5/6/7 cables. Moreover SP-5564 is cascadable and allows users to extend Full HD A/V to HDMI compliant displays almost anywhere. For convenience, SP-5564 is also equipped with a local 5x1 HDMI switch for input selection. With the built in equalization for HDMI inputs, the input HDMI cable can actually be extended up to 20 meters/66 feet long under Full HD, and make the overall transmission distance superior than regular HDMI splitters or matrix switches in the market.

    SPECIFICATIONS
    Technical
    • HDMI Compliance
    • 1.3

    • HDCP Compliance
    • 1.1

    • Max. Distance
    • Up to 1080p60@40m (Cat 5e/6) -@50m (Cat 6a)
      Up to 720p60@60m (Cat 5e/6) -@70m (Cat 6a)

    • Max. Data Rate
    • 6.75 Gbps

    • Max. Resolution
    • 1080p@60 (4:2:2—12bits)
      1080p@60 (4:4:4—8bits)

    • Audio Support
    • Dolby TrueHD, DTS-HD Master Audio, Dolby Digital Plus, LPCM 7.1 Audio

    • CEC control
    • Pass through

    • RS232 Control
    • Full Duplex (115,200 bps)

    • ESD Protection
    • 8 KV—Contact Discharge
      15KV—Air Discharge

    Mechanical
    • Housing Design
    • Metal

    • Casing Style
    • Rack Mountable

    • Power Connection
    • non-locking Barrel

    • Power Supply
    • AC Power 100-240V

    • Power Consumption
    • 100 watts (Max.)

    • Operating Humidity
    • 20-90% RH (no condensation)

    • Operation temperature
    • 0~40°C (32~104°F)

    • Product Weight
    • 4394g (9.7 lbs)

    • Package Weight
    • 5400g (11.9 lbs)

    • Certifications
    • CE, FCC, RoHS
