SW-5005RS
5-Port True 4K HDMI Switch
- Routes 5 HDMI sources to One Display
- Intelligent Auto-Switching
- Touch control with beep sound
- Clear Illuminate LED digit-numbering
- Latest HDMI 2.0 Switch
Overview
The SW-5005RS 5-port True 4K UHD HDMI Switcher supports HDMI 2.0 compliant, 4K UHD media playback at up to 60fps for great picture clarity. Brand-new user-friendly control method, displaying indicator and multifunctional design in appearance, all are engineered to become truly handy gadget for users in a wide range of settings.
For anyone who has the basics of home theater set-up with TV display or of entertainment console set-up with PC monitor, the GoMax five-port HDMI switch box is the ideal choice. With five HDMI inputs, you can connect your cable or satellite box, streaming device, Blu-ray player, or DVD player without having a tangled mess of cables running to your TV display or PC monitor.
This unit unprecedentedly features a white backlight digit LED display to let you know which port is in use within eyesight (no dizzy feeling caused by a dazzling light from LED diode).
Another intriguing facet of the SW-5005R is built-in touch control underneath the front panel, user can effortlessly swap between inputs with gentle touch by fingertip in arm-reach range, meanwhile the unit emits a tiny 「beep」 with every tap, allowing user to localize which input coming next.
At less than a 0.7 inch thick, 6.3 inch wide and 3.0oz, it is compact enough to attach to any edge bezel of TV display or PC monitor and perfect enough to mesh together various HDMI cables along with on-focus LCD screen. This exquisite piece of HDMI switch box is designed for those who want to have it both ways, awesome functionality in operation and sophisticated taste in organization.
For anyone who has the basics of home theater set-up with TV display or of entertainment console set-up with PC monitor, the GoMax five-port HDMI switch box is the ideal choice. With five HDMI inputs, you can connect your cable or satellite box, streaming device, Blu-ray player, or DVD player without having a tangled mess of cables running to your TV display or PC monitor.
This unit unprecedentedly features a white backlight digit LED display to let you know which port is in use within eyesight (no dizzy feeling caused by a dazzling light from LED diode).
Another intriguing facet of the SW-5005R is built-in touch control underneath the front panel, user can effortlessly swap between inputs with gentle touch by fingertip in arm-reach range, meanwhile the unit emits a tiny 「beep」 with every tap, allowing user to localize which input coming next.
At less than a 0.7 inch thick, 6.3 inch wide and 3.0oz, it is compact enough to attach to any edge bezel of TV display or PC monitor and perfect enough to mesh together various HDMI cables along with on-focus LCD screen. This exquisite piece of HDMI switch box is designed for those who want to have it both ways, awesome functionality in operation and sophisticated taste in organization.
SPECIFICATIONS
Technical
-
HDMI Compliance
-
2.0b
-
HDCP Compliance
-
2.2／1.4
-
Max. Data Rate
-
18 Gbps
-
Max. Resolution
-
4K2K@60 (4:2:0—10bits)
4K2K@60 (4:4:4—8bits)
-
HDR
-
4:2:0|4:2:2|4:4:4—10 or 12bits／HDR10; HDR10+; Dolby Vision; HLG
-
Audio Support
-
Dolby TrueHD, DTS-HD Master Audio, Dolby Digital Plus, LPCM 7.1 Audio
-
CEC control
-
Pass through
-
ESD protection
-
8 KV—Contact Discharge
15KV—Air Discharge
Mechanical
-
Housing Design
-
Metal
-
Casing Style
-
Portable
-
Power Connection
-
Micro-USB Port
-
Power Supply
-
5V DC, 1A
-
Power Consumption
-
3 watts (Max.)
-
Operating Humidity
-
20-90% RH (no condensation)
-
Operation temperature
-
0~40°C (32~104°F)
-
Product Weight
-
85g (3.0 oz.)
-
Package Weight
-
245g (8.6 lbs)
-
Certifications
-
CE, FCC, RoHS
