    CV-C03S
    HDMI/DP/VGA to 3G/HD/SD-SDI Scaler Converter
    • Supports Input HDMI1.3 /DP1.1/ VGA
    • IR remote control
    • Button control
    • Remote control via Micro-USB
    • OSD control interface
    • Support two SDI output
    • Input maximum pixel rate : 165MHz
    • Output bandwidth 2.970Gpbs
    • Supports multiple VESA resolutions
    • Deinterlacer supported
    • Supports video enhancement features
    • Over / under scanning adjustable
    • Video H/V mirror supported
    • Active video area adjustment supported
    • Stable and independent output signal quality.
    • USB firmware upgradable for expanding compatibility
    • Wall-mount housing design for easy installation
    Overview

    The CV-C03S HDMI/DP/VGA to 3G/HD/SD-SDI Scaler Converter provides a professional way to scale and convert multiple format (HDMI/DP/VGA) to 3G/HD/SD-SDI format. This device supports video conversion and scaling from analog & digital to 3G/HD/SD-SDI. The conversion between HDMI/DP and SDI is pure digital and guarantees no loss transformation for both audio and video. Besides, VGA based devices such as PC with analog stereo audio can readily connect to your SDI TV. The CV-C03S provides low jitter SDI output.

    SPECIFICATIONS
    Technical
    • HDMI Compliance
    • 1.3

    • SDI Formats
    • SMPTE 424M-2.97 Gbps/3G-SDI 1080p at 50/59.94/60 Hz (4:2:2)。
      SMPTE 274M-1.485 Gbps/HD-SDI:1080p at 23.98/24/25/29.97/30 Hz, 1080i at 50/59.94/60 Hz。
      SMPTE 292M-1.485 Gbps/HD-SDI:1080i at 30 Hz, 720p at 60 Hz。
      SMPTE 296M-1.485 Gbps/HD-SDI:720p at 23.98/24/25/29.97/30/50/59.94/60 Hz。
      SMPTE 259M-270 Mbps/SD-SDI:NTSC 525 at 59.94 Hz, PAL 625 at 50 Hz。

    • HDMI Formats
    • UHD Video Standards/1080p at 50/59.94/60 Hz (4:2:2)
      HD Video Standards/720p at 50/59.94/60 Hz, 1080i at 50/59.94/60 Hz, 1080p at 23.98/24/25/29.97/30 Hz
      SD Video Standards/NTSC at 59.94 Hz, PAL at 50 Hz

    • SDI Bitrate
    • 270 Mbps, 1.485 Gbps, 2.97 Gbps

    • Video Sampling
    • 4:2:2

    • Audio Sampling
    • 48 kHz & 24 bit

    • Auto Switching
    • Auto switching between SD/HD/3G-SDI

    • Cable Reach
    • [3G-SDI] up to 90m (300ft)
      [HD-SDI] up to 150m (500ft)
      [SD-SDI] up to 300m (1000ft)

    • Eye-patten Measurements
    • Amplitude:within 800mV
      Raise&Fall time:<45ps> Timing jitter:<8> Alignment jitter:<0.3(100KHz to 1188MHz)

    • ESD Protection
    • 8 KV—Contact Discharge
      15KV—Air Discharge

    Mechanical
    • Housing Design
    • Metal

    • Casing Style
    • Metal

    • Power Connection
    • Interlocking Barrel

    • Power Supply
    • 12V DC, 2A

    • Power Consumption
    • 6 watts (Max.)

    • Operating Humidity
    • 20-90% RH (no condensation)

    • Operation temperature
    • 0~40°C (32~104°F)

    • Product Weight
    • 223g (0.4 lb.)

    • Package Weight
    • 683g (1.5 lb.)

    • Certifications
    • CE, FCC, RoHS
