- Extends the HDMI transmission up to 70m (230ft) from the HDMI source at Full HD 1080p 48-bit, and 40m (130ft) at 4K2K@60Hz (YUV 4:2:0)
- Supports HDMI Deep Color, full 3D, 4K2K@60Hz (YUV 4:2:0)
- Supports PoC(Power over Cable) which can power both units from TX side with power supply
- HDCP1.4 & HDCP2.2 compliant
- Bi-directional IR pass-though
- Allows controlling local HDMI sources or display through control path
- Allows to control matrix switcher through control line at remote receiver
- Pure unaltered uncompressed 7.1ch digital HDMI over Cat.5/5e/6 cable transmission
- Allows any source to be displayed on multiple displays at the same time
- Allows any HDMI display to view any HDMI source at any time
- Supports 7.1 channel digital audio
- Supports default HDMI EDID and learns the EDID of displays to matrix switcher
- The matrix switcher can switch every output channels from any HDMI inputs by Push button, IR remote control, RS-232, IP control and web-interface control
- Easy installation with rack-mounting
- Fast response time – 2~4 seconds for channel switch
The MA-5444V2 4x4 HDBaseT Lite matrix with PoC, HDCP2.2 & 4K2K60 (YUV420) provides the most flexible and cost effective solution in the market to route high definition video sources plus multi-channel (up to 7.1-channel) digital audio from any of the eight HDMI sources to the remote displays at the same time. Through only one low cost Cat-5/5e/6 LAN cables, not only high quality video and audio can be transmitted to the display sites, but also users can switch among eight HDMI sources using the push button or remote control. Furthermore, the built-in IR extension function makes users at display site access the DVD player, PS3 or any HDMI supported devices directly! In addition, MA-5444V2 also supports PoC (Power over Cable) which can power both units from TX with power supply.
-
HDMI Compliance
-
2.0
-
HDCP Compliance
-
2.2／1.4
-
Max. Distance
-
Up to 4Kp60@40m (Cat 5e/6) -@70m (Cat 6a)│1080p60@60m
-
Max. Data Rate
-
10.2 Gbps
-
Max. Resolution
-
4K2K@60 (YUV420)
-
Audio Support
-
Dolby TrueHD, DTS-HD Master Audio, Dolby Digital Plus, LPCM 7.1 Audio
-
CEC control
-
Pass through
-
IR Control
-
Two Way
-
IR Frequency
-
38—56 KHZ
-
RS232 Control
-
Full Duplex (115,200 bps)
-
ESD protection
-
8 KV—Contact Discharge
15KV—Air Discharge
-
POC
-
UNIdirectional (TX→RX)
-
Housing Design
-
Metal
-
Casing Style
-
Rack Mountable
-
Power Connection
-
Interlocking Barrel
-
Power Supply
-
24V DC, 3.75A
-
Power Consumption
-
70 watts (Max.)
-
Operating Humidity
-
20-90% RH (no condensation)
-
Operation temperature
-
0~40°C (32~104°F)
-
Product Weight
-
1.8kg (4 lbs)
-
Package Weight
-
3.5kg (7.7 lbs)
-
Certifications
-
CE, FCC, RoHS
