    SP-5105KC
    1x4 HDMI splitter over single cat.X with local out & full 3D support
    • Support HDMI Deep Color & full 3D
    • HDCP compliant
    • Regenerates the HDMI signal
    • HDMI local output for monitoring
    • Supports default HDMI EDID and has the ability to learn the EDID of displays
    • Extends up to 20m (66ft) of input HDMI cable
    • Extends up to 60m (200ft) of output Cat-5/5e/6 solid UTP cable under HD (720p / 1080i)
    • Extends up to 40m (130ft) of output CAT-5/5e/6 solid UTP cable under Full HD (1080p)
    • Pure unaltered uncompressed 7.1ch digital HDMI over CAT5e/6 cable transmission
    • Allows cascading
    • Perfectly integrated with other HDMI over CAT5 series products
    Overview

    The SP-5105KC 1x4 HDMI & Full 3D support over Single CAT5 Distribution Amplifier with Local Output provides the most flexible solution by which the high definition video and high quality audio can be transmitted to different locations over a long distance. The devices are cascadable, allowing you to extend HDMI compliant displays almost anywhere. The input HDMI source can be duplicated and distributed to up to 4 HDMI enable displays through cost effective Cat-5/5e/6 cables with HDMI over CAT5 receivers (CV-735 and/or CV-715s). For convenience, SP-5105KC is also equipped a local HDMI output for monitoring. With the built in equalization, the input HDMI cable can be extended up to 20 meters (66 feet) long under Full HD, and make the overall transmission distance superior than regular HDMI splitters or matrix switches in the market.

    SPECIFICATIONS
    Technical
    • HDMI Compliance
    • 1.3

    • HDCP Compliance
    • 1.1

    • Max. Distance
    • Up to 1080p60@40m (Cat 5e/6) -@50m (Cat 6a)
      Up to 720p60@60m (Cat 5e/6) -@70m (Cat 6a)

    • Max. Data Rate
    • 6.75 Gbps

    • Max. Resolution
    • 1080p@60 (4:2:2—12bits)
      1080p@60 (4:4:4—8bits)

    • Audio Support
    • Dolby TrueHD, DTS-HD Master Audio, Dolby Digital Plus, LPCM 7.1 Audio

    • CEC control
    • Pass through

    • ESD protection
    • 8 KV—Contact Discharge
      15KV—Air Discharge

    Mechanical
    • Housing Design
    • Metal

    • Casing Style
    • Wall Mountable

    • Power Connection
    • Interlocking Barrel

    • Power Supply
    • 5V DC, 4A

    • Power Consumption
    • 13 watts (Max.)

    • Operating Humidity
    • 20-90% RH (no condensation)

    • Operation temperature
    • 0~40°C (32~104°F)

    • Product Weight
    • 588g (1.2 lbs)

    • Package Weight
    • 1000g (2.2 lbs)

    • Certifications
    • CE, FCC, RoHS
