EX-36O1
12G/6G/3G/HD-SDI over Fiber Extender with, RS-232, 1G Ethernet, USB 3.1 & KVM Support
- Supported high-definition (HD) formats:
- 720p@50,720p@59.94, 720p@60, 1080i@50, 1080i@59.94, 1080i@60, 1080p@23.97, 1080p@24, 1080p@25, 1080p@29.97, 1080p@30, 1080p@50, 1080p@59.94, 1080p@60, 3840x2160@23.98, 3840x2160@24, 3840x2160@25, 3840x2160@29.97, 3840x2160@30, 3840x2160@50, 3840x2160@59.94, 3840x2160@60, 4096x2160@23.98, 4096x2160@24, 4096x2160@25, 4096x2160@29.97, 4096x2160@30, 4096x2160@50, 4096x2160@59.94, 4096x2160@60 Bit Rate: 11.88 Gbps, 11.88/1.001 Gbps, 5.94 Gbps, 5.94/1.001 Gbps, 2.97 Gbps, 2.97/1.001 Gbps, 1.485 Gbps, 1.485/1.001 Gbps, 270 Mbps
- Extend signals over single-mode fiber for distances exceeding 2 km and up to 10+ km.
- Extend SDI signals up to 10+ km (6.25+ miles) over single mode fiber optic cables
- Full duplex RS-232 control up to 115,200 bps
- Supports USB 3.1 Gen1 host mode for UVC webcam and USB 3.1 Gen2 UVC device mode
- Supports KVM function
- Integrated 1G Ethernet for LAN/network device
Overview
The EX-36O1 12G/6G/3G/HD-SDI over Fiber Extender with, RS-232, 1G Ethernet, USB 3.1 & KVM Support is a high-performance AV transmission solution tailored for modern multimedia applications. It supports video resolutions up to 4K60, delivering exceptional image quality and zero-frame latency, making it ideal for professional AV setups. Leveraging single-mode fiber technology, this extender enables video and audio transmission over distances ranging from 2 km to an impressive 10+ km. Additionally, it features USB 3.0 for modern peripherals, 1Gb Ethernet, and RS-232, providing seamless connectivity and versatile control for demanding AV environments.
SPECIFICATIONS
Technical
-
Video Bandwidth
-
[SDI][ 11.88 Gbps, 11.88/1.001 Gbps]
-
Video Support
-
[12G] 4K2K @50/59.94/60Hz; [6G] 4K2K @23.98/24, 25, 29.97, 30Hz; [3G] 1080p50/59.94/60; [HD] – 720p @50/59.94/60Hz,1080i @50/59.94/60Hz, 1080p @23.98/24/25/29.97/30Hz
-
SDI over Fiber
-
4K2K@60 up to 10+ km (6.25+ miles) [single mode fiber optic cable]
-
Audio support
-
Surround sound [up to 7.1ch]
-
RS-232 support
-
Yes
Mechanical
-
Housing Design
-
Metal
-
Casing Style
-
Wall Mountable
-
Power Connection
-
Interlocking Barrel
-
Power Supply
-
12V DC, 1A
-
Power Consumption
-
10 watts (Max.)
-
Operating Humidity
-
20-90% RH (no condensation)
-
Operation temperature
-
0~40°C (32~104°F)
-
Product Info
-
Dimensions：175 (L) x 112 (D) x 34 (H) mm Weight：tx-0.6kg / rx-0.6kg
-
Certifications
-
CE, FCC, RoHS
