CV-305KZ
12G/6G/3G/HD/SDI to HDMI 2.0 Converter
  • Supported high-definition (HD) formats:
  • NTSC 525@59.94, PAL 625@50, 720p@50,720p@59.94,
  • 720p@60, 1080i@50, 1080i@59.94, 1080i@60, 1080p@23.97,
  • 1080p@24, 1080p@25, 1080p@29.97, 1080p@30, 1080p@50,
  • 1080p@59.94, 1080p@60, 4K2K@23.97, 4K2K@24, 4K2K@25,
  • 4K2K@30, 4K2K@50, 4K2K@59.94, 4K2K@60,
  • Bit Rate: 2.97 Gbps, 2.967 Gbps, 1.485 Gbps, 1.4835 Gbps, 270 Mbps
  • Auto 12G/6G/3G/HD/SD-SDI detection
  • Support HDMI 2.0
  • One SDI compliant output and one HDMI compliant output
總覽
The CV-305KZ 12G/6G/3G/HD/SD-SDI to HDMI 2.0 Converter provides a professional way to convert 12G/6G/3G/HD/SD-SDI to HDMI 2.0 in real time. The conversion between SDI and HDMI is pure digital and guarantees no loss transformation for both audio and video. Plus, with up to 8 channel audio support, 7.1 channel or 5.1 channel audio becomes available. The CV-305KZ also provides one low jitter and re-clocked output for daisy chain or multiple monitors.

產品規格
Technical
  • HDMI Compliance

  • 2.0

  • SDI Formats

  • SMPTE 2082; 11.88 Gbps／12G-SDI：2160p at 50/59.95/60 Hz。
    SMPTE 2081; 5.94 Gbps／6G-SDI：2160p at 25/29.97/30 Hz。
    SMPTE 424M; 2.97 Gbps／3G-SDI 1080p at 50/59.94/60 Hz (4:2:2)。
    SMPTE 274M; 1.485 Gbps／HD-SDI：1080p at 23.98/24/25/29.97/30 Hz, 1080i at 50/59.94/60 Hz。
    SMPTE 296M; 1.485 Gbps／HD-SDI：720p at 23.98/24/25/29.97/30/50/59.94/60 Hz。
    SMPTE 292M; 1.485 Gbps／HD-SDI：1080i at 30 Hz, 720p at 60 Hz。
    SMPTE 259M; 270 Mbps／SD-SDI：NTSC 525 at 59.94 Hz, PAL 625 at 50 Hz。

  • HDMI Formats

  • 4K UHD Video Standards／2160p at 23.98/24/25/29.97/30/50/59.94/60 Hz
    UHD Video Standards／1080p at 50/59.94/60 Hz (4:2:2)
    HD Video Standards／720p at 50/59.94/60 Hz, 1080i at 50/59.94/60 Hz, 1080p at 23.98/24/25/29.97/30 Hz
    SD Video Standards／NTSC at 59.94 Hz, PAL at 50 Hz

  • SDI Bitrate

  • 270 Mbps, 1.485 Gbps, 2.97 Gbps, 5.94 Gbps, 11.88 Gbps

  • Video Sampling

  • 4：2：2

  • Audio Sampling

  • 48 kHz & 24 bit

  • Auto Switching

  • Auto switching between SD／HD／3G／6G／12G-SDI

  • Cable Equalization

  • [12G-SDI] up to 60m (200ft)
    [6G-SDI] up to 75m (250)
    [3G-SDI] up to 90m (300ft)
    [HD-SDI] up to 150m (500ft)
    [SD-SDI] up to 300m (1000ft)

  • Eye-patten Measurements

  • Amplitude：within 800mV
    Raise&Fall time：<45ps> Timing jitter：<8> Alignment jitter：<0.3(100KHz to 1188MHz)

  • ESD Protection

  • 8 KV—Contact Discharge
    15KV—Air Discharge

Mechanical
  • Housing Design

  • Metal

  • Casing Style

  • Wall Mountable

  • Power Connection

  • Interlocking Barrel

  • Power Supply

  • 12V DC, 2A

  • Power Consumption

  • 9 watts (Max.)

  • Operating Humidity

  • 20-90% RH (no condensation)

  • Operation temperature

  • 0~40°C (32~104°F)

  • Product Weight

  • 430g (1.0lb.)

  • Package Weight

  • 866g (1.9lb.)

  • Certifications

  • CE, FCC, RoHS
