CV-005S
Component/CVBS & audio to HDMI Scaler Converter
- IR remote control
- Remote control via Mini-USB
- OSD control interface
- Maximum pixel rate : 165MHz
- 525i, 625i, 525P, 625P, 720P, 1080i and many other HDTV formats are supported
- S/PDIF input supported
- Deinterlacer supported
- Supports nosie reduction and video enhancement features
- Over / Under scanning adjustable
- Video H/V mirror supported
- Active video area adjustment supported
- USB firmware upgradable for expanding compatibility
- Wall-mount housing design for easy installation
總覽
The CV-005S Component/CVBS & audio to HDMI Scaler Converter provides a cost effective way to convert Component or CVBS signal to HDMI compliant format. CV-005S supports the S/PDIF audio thru RCA into HDMI output. With this extra feature, users can combine asynchronous video and audio sources into the state-of-art HDMI compliant A/V signal for having high standard A/V experiences!
產品規格
Technical
-
HDMI Compliance
-
1.2
-
HDCP Compliance
-
1.4
-
Max. Data Rate
-
4.95 Gbps
-
Max. Resolution
-
1080p@60 (4:2:2—12bits)
1080p@60 (4:4:4—8bits)
-
Audio Support
-
Stereo PCM
-
ESD protection
-
8 KV—Contact Discharge
15KV—Air Discharge
Mechanical
-
Housing Design
-
Metal
-
Casing Style
-
Wall Mountable
-
Power Connection
-
Interlocking Barrel
-
Power Supply
-
5V DC, 2A
-
Power Consumption
-
5 watts (Max.)
-
Operating Humidity
-
20-90% RH (no condensation)
-
Operation temperature
-
0~40°C (32~104°F)
-
Product Weight
-
270g (0.6 lb.)
-
Package Weight
-
520g (1.2 lb.)
-
Certifications
-
CE, FCC, RoHS
